8. Perform “BUS PIP HSL-04” on page 303, then return here and continue with
step 9 of this procedure.
9. Use the system model, tower, expansion unit or machine type and the table
below to determine the service information for the failing component.
Table 33.
System Model,
Towe r,
Expansion
Unit, or
Machine Type
Name of FRU
to Exchange
FRU Position Link to
Location
Diagram
Link to Failing
Component Service
Information. (CCIN,
PN, Removal and
Installation Procedure)
FC 5074 HSL I/O
Bridge Card
C08 “Locations —
FC 5074 I/O
Tower” on
page 736.
Table 44 on page 737.
FC 5075 Tower Card CB1 “Locations —
FC 5075 I/O
Tower” on
page 740.
Table 45 on page 741.
FC 5078/0578 HSL I/O
Bridge Card
C08 “Locations —
FC 5078, 0578
PCI Expansion
Unit” on
page 743.
Table 46 on page 744.
FC 5079 (1.8m
expansion
tower)
HSL I/O
Bridge Card
C08 “Locations —
FC 5079 I/O
Tower” on
page 747.
Table 44 on page 737.
Models 830
and SB2 base
I/O tower (FC
9074)
HSL I/O
Bridge Card
C08 “Locations —
Models 830,
SB2 System
Unit with FC
9074 Base I/O
Tower” on
page 709.
Table 41 on page 710.
Models 840
and SB3 base
I/O tower (FC
9079)
HSL I/O
Bridge Card
C08 Figure 36 on
page 724.
Table 43 on page 725.
External
xSeries Server
Integrated
xSeries
Adapter Card
Follow the
HSL cables.
Go to
“Locations —
Integrated
xSeries
Adapter Card
(IXA),
Formerly the
Adapter for
Netfinity
Server” on
page 748.
Go to Table 47 on
page 749.
FC 5077 SPD
Migrated
Tower
Go to symbolic FRU LBUSADP in the Migrated Expansion Tower Problem
Analysis, Repair and Parts.
Symbolic FRUs
586
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
