k. Click the Settings tab.
l. Click the ASCII Setup button.
m. Select the following options so they have a check mark in the preceding
box:
v Send line ends with line feeds
v Echo typed characters locally
v Append line feeds to incoming line ends
v Wrap lines that exceed terminal width
n. Click OK.
o. Click OK.
p. At the system’s control panel, or use the remote control panel if installed
with Operations Console, perform a function 25, then a function 26 to gain
access to the extended (upper) functions.
q. Perform a function 65. This may or may not result with information going
to the Hyperterminal window or SRC D1008065 being displayed at the
control panel.
r. Perform a function 66. This may or may not result with information going
to the Hyperterminal window or SRC D1008066 being displayed at the
control panel.
s. Using UPPERCASE, type NEGOTIATE 2 in the Hyperterminal window.
Then, press the Enter key.
t. Wait at least 30 seconds. If no data is returned, do step 4s again.
u. If there is full connectivity between the PC and the iSeries 400 a valid
modem speed will be returned. If no data was returned, there is no
connectivity and you should replace each of the following items, one at a
time, and repeat this test:
v Operations Console cable, P/N 97H7557
v 2745 IOA
v 2771 IOA
If replacing the IOA did not fix the problem there is probably something wrong
with the PC or the Operations Console setup which will require support from
someone with Operations Console software training to resolve.
Operations Console-PIP2
This problem isolation procedure will isolate a failure with the remote control
panel.
This PIP works with cable-connected configurations only.Itisnot valid for
network or dial connected configurations.
The following symptoms can be caused by a defective remote control panel cable:
v Remote control panel (hung) System control panel functions.
v SRC 0000 DDDD with attention light on the system panel.
Note: This SRC can also show up temporarily for valid reasons. It is only a
problem if the SRC remains constant.
v Remote control panel accepts mode selections, however the system does not
respond.
v The remote control panel does not function.
v iSeries 400 Operations Console status is ″Connecting remote control panel″.
Operations Console PIPs
Chapter 3. Problem Isolation Procedures (PIPs), Failing Items, and Symbolic FRU Isolation 383
