Table 48. IOP, IOA, and device address information for Models 830, SB2 System Unit with
FC 9074 Base I/O Tower (continued)
Position Possible Failing
Component
DSA (BBBBCcbb)
Note: IOA and
device DSA’s will not
follow the rules
below if the IOA is
manually reassigned
after IPL.
Unit Address
D50 Disk Unit 0001-10-00 420700FF
Addresses — Models 840, SB3 Processor Tower and FC 9079
Base I/O Tower
Use the address to find the location. Then go to Table 42 on page 720 to find
additional information.
Table 49. IOP, IOA, and device address information for FC 9079 Base I/O Tower (On
Models 840, SB3)
Position Possible Failing
Component
DSA (BBBBCcbb)
Note: IOA and
device DSA’s will not
follow the rules
below if the IOA is
manually reassigned
after IPL.
Unit Address
CB1 Service Processor 0001-70-00 FFFFFFFF
C01 IOP 0001-10-00 FFFFFFFF
C02 Comm/Wkst IOA 0001-10-00 E2FFFFFF
C03 Storage IOA 0001-10-00 4FFFFFFF
C04 Storage IOA The IOA has the
same DSA as the first
IOP found in the
following list: C03,
C01.
6FFFFFFF
Comm/Wrkst IOA E6FFFFFF
C05 (IXS capable
position)
IOP yyyy-10-00 FFFFFFFF
C06 (empty if IXS in
C05)
Storage IOA yyyy-10-00 2FFFFFFF
Comm/Wrkst IOA yyyy-10-00 E2FFFFFF
C07 IOP yyyy-13-00 FFFFFFFF
Storage IOA yyyy-10-00 3FFFFFFF
Comm/Wrkst IOA yyyy-10-00 E3FFFFFF
IXS attached IOA yyyy-10-00 E003FFFF
C09 IOP yyyy-14-00 FFFFFFFF
Storage IOA yyyy-10-00 4FFFFFFF
Comm/Wrkst IOA yyyy-10-00 E4FFFFFF
IXS attached IOA yyyy-10-00 E004FFFF
Locations and Addresses
758
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
