handle from right to left.
After exchanging an item, go to “Verifying the Repair” on page 920.
This ends the procedure.
Models 830/SB2 with FC 9074 – Removable Media (D41 & D42)
Laser Safety Information
CAUTION:
This product may contain a CD-ROM which is a class 1 laser product.
(RSFTC240)
Note: Determine if the system has logical partitions. Go to “Determining if the
System Has Logical Partitions” on page 943, before continuing with this
procedure.
1. Remove media (if any) from the device. If the eject button on a tape device is
failing, go to “Tape Cartridge – Manual Removal” on page 701, then continue
with the next step of this procedure. If the eject button on an optical media
device (CD-ROM or DVD) is failing and will not open, go to “Optical Media –
Manual Removal” on page 704, and then continue with the next step of this
procedure.
2. Are you removing a unit by using device concurrent maintenance?
Yes No
↓
a. Power off the expansion tower. (see “Powering On and Powering
Off the System and Logical Partitions” on page 922)
b. Disconnect the power cord from the expansion tower.
c. Open the front cover. (See “Models 830/SB2 with FC 9074 – Covers”
on page 663.)
d. Pull on the handles which are located on each side of the unit and
remove the unit.
e. Install the new device by reversing the removal procedure. After
exchanging an item, go to “Verifying the Repair” on page 920.
f. If you need to remove a tape from the old tape unit, see “Tape
Cartridge – Manual Removal” on page 701.
g. If you need to remove a CD-ROM or DVD media, go to “Optical
Media – Manual Removal” on page 704, and then continue with the
next step of this procedure.
This ends the procedure.
3. Before exchanging a removable media unit, you must ensure that the unit is not
in use and is varied off.
4. Use the figure to determine the location of the internal removable media unit.
Record this location for later use.
Remove and Replace Procedures
Chapter 4. Removal and Installation Procedures 671
