Table 35. (continued)
System Model, Tower, Expansion Unit or
Machine Type
HSL Cable or Connections
FC 5033, FC 5034, FC 5035 SPD migrated
towers
v External HSL ports on the frame.
v An HSL interposer card inside the frame
behind the external HSL ports.
v An internal ribbon cable connecting the
Tower Card in position C00 to the HSL
interposer card inside the frame behind
the external HSL ports.
FC 5077 SPD migrated towers
v External HSL ports on the frame.
v An HSL interposer card in position S08.
This ends the procedure.
SIRGCFG
An invalid configuration was detected on an HSL loop during IPL.
The 4 rightmost characters of word 4 contains a Program Return Code (PRC)
which describes the problem detected. The leftmost 4 digits of word 7, in the SRC
contains the loop number in hexadecimal format. Convert the loop number to
decimal format before comparing it to loop numbers shown in HSM.
To determine the problem, find the PRC in the table below.
Note: The FRU description in the SAL may already contain a message that
identifies the problem.
PRC in Word 4 of the SRC Problem Identified Corrective Action
xxxx 0008 SYSTEM SERIAL NUMBER
NOT SET
Set the serial number on the
system unit. If the problem
persists contact your next
level of support.
xxxx 3200 CLUSTERED SYSTEM(S) ON
LOOP WITH SPD
MIGRATED TOWER
Remove clustered systems
from the loop with the
migration tower.
xxxx 3201 CLUSTERED SYSTEMS ON
MULTIPLE HSL LOOPS
Ensure all clustered systems
are on the same HSL loop.
xxxx 3202 MULTIPLE SPD MIGRATED
TOWERS DETECTED
Only one migration tower is
supported on a system.
Remove the additional
migration towers.
xxxx 3207 SPD MIGRATED TOWER
NOT ON FIRST HSL LOOP
Move the migration tower to
the first HSL loop. The first
HSL loop is number 256 and
attaches to ports A0 and A1
on the network interface
controller (NIC) card of the
system unit. The first HSL
loop connects to the system
frame at HSL ports A0 and
A1.
Symbolic FRUs
590
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
