Table 35.
System Model, Tower, Expansion Unit or
Machine Type
HSL Cable or Connections
Models 830 and SB2 system unit
v
Note: The HSL cable ports A0 and A1 (for
loop # 256) are not on the Network
Interface Controller NIC card in position
M06.
– The ″A0″ port is labeled ″1″ and is
located on the HSL I/O bridge card in
position C08 of the FC 9074 base I/O
tower.
– Port ″A1″ is located on the system unit
frame under the NIC card in position
M06. The ″A1″ port is oriented
horizontally below a cross member of
the frame.
v An internal ribbon cable connecting the
Network Interface Controller (NIC) card
in position M06 to the HSL I/O bridge in
position C08 of the FC 9074 base I/O
tower. (The first link on HSL loop 256).
v HSL ports are on the Network Interface
Controller (NIC) Card in position M06.
Models 830 and SB2 base I/O tower (FC
9074)
v An internal ribbon cable connecting the
HSL I/O bridge in position C08 to the
system unit’s Network Interface Controller
(NIC) card in position M06. (The first link
on HSL loop 256).
v External HSL port on the HSL I/O bridge
card in position C08.
Models 840 and SB3 system unit/processor
tower
v HSL ports are on the Network Interface
Controller (NIC) Card in position M17.
Models 840 and SB3 base I/O tower (FC
9079)
v External HSL ports on the HSL I/O bridge
card in position C08.
FC 5074
v External HSL ports on the HSL I/O bridge
card in position C08.
FC 5075
v External HSL ports on the tower frame.
v Internal ribbon cable connecting the frame
to the tower card in position CB1.
FC 5078/0578
v External HSL ports on the HSL I/O bridge
card in position C08.
FC 5079 (1.8m expansion tower)
v External HSL ports on the HSL I/O bridge
card in position C08.
External xSeries Server
v External HSL ports on the Integrated
xSeries Adapter
Symbolic FRUs
