Table 68. FC 5074 I/O Tower – Dual Line Cord Signal Cables
Name Description Part Number
SIG60 IOA in Tower Card (CB1) to
Device Board 3 (DB3)
97H7481
SIG61 IOA in Tower Card (CB1) to
Device Board 2 (DB2)
44L0070
SIG62 IOA in Tower Card (CB1) to
Device Board 1 (DB1)
97H7484
SIG63 Control Panel (NB1) to
Device Board 3 (DB3)
24L1752
SIG64 Tower Card (CB1) to Power
Distribution Board (PB1 -
includes P/N 97H7476,
97H7477, 97H7607) (Part of
Tower Card FRU assembly)
24L0843
Table 69. FC 5074 I/O Tower – Dual Line Cord Power Cables
Name Description Part Number
PWR60 Power Distribution Board
(PB1) to Device Board 3
(DB3)
24L1886
PWR61 to PWR64 Power Distribution Board
(PB1) to Device Board 3
(DB3)
97H7483
PWR65 Power Distribution Board
(PB1) to Device Board 2
(DB2)
97H7544
PWR66 to PWR69 Power Distribution Board
(PB1) to Device Board 2
(DB2)
97H7543
PWR70 Power Distribution Board
(PB1) to Device Board 1
(DB1)
97H7544
PWR71 to PWR74 Power Distribution Board
(PB1) to Device Board 1
(DB1)
97H7543
PWR75 Power Distribution Board
(PB1) to AMDs (B01 and
B02)
97H7475
PWR77 Charger (A01) to Power
Supply 1 (P01)
04N2181
PWR78 Charger to Power Supply 2
(P02)
04N2181
FC 5075 I/O Tower
Power and Signal Cables
Chapter 5. Locations, Addresses, and Part Listings 799
