Table 30.
System Model,
Towe r,
Expansion
Unit, or
Machine Type
Name of FRU
to Exchange
FRU Position Link to
Location
Diagram
Link to Failing
Component Service
Information. (CCIN,
PN, Removal and
Installation Procedure)
FC 5074 HSL I/O
Bridge Card
C08 “Locations —
FC 5074 I/O
Tower” on
page 736.
Table 44 on page 737.
FC 5078/0578 HSL I/O
Bridge Card
C08 “Locations —
FC 5078, 0578
PCI Expansion
Unit” on
page 743.
Table 46 on page 744.
FC 5079 (1.8m
expansion
tower)
HSL I/O
Bridge Card
C08 “Locations —
FC 5079 I/O
Tower” on
page 747.
Table 44 on page 737.
Models 830
and SB2 base
I/O tower (FC
9074)
HSL I/O
Bridge Card
C08 “Locations —
Models 830,
SB2 System
Unit with FC
9074 Base I/O
Tower” on
page 709.
Table 41 on page 710.
Models 840
and SB3 base
I/O tower (FC
9079)
HSL I/O
Bridge Card
C08 Figure 36 on
page 724.
Table 43 on page 725.
External
xSeries Server
Integrated
xSeries
Adapter Card
Follow the
HSL cables.
Go to
“Locations —
Integrated
xSeries
Adapter Card
(IXA),
Formerly the
Adapter for
Netfinity
Server” on
page 748.
Go to Table 47 on
page 749.
This ends the procedure:
SI_CARD
SI_CARD: high-speed link Controller Card.
The failing component is the network interface controller (NIC) card in the system
unit.
Use the system model and the table below to determine the service information for
the failing component.
Symbolic FRUs
Chapter 3. Problem Isolation Procedures (PIPs), Failing Items, and Symbolic FRU Isolation 583
