Table 72. FC 5078, 0578 I/O Tower Signal Cables

Name Description Part Number

SIGC01 Control Panel (NB1) to

Control Panel connector

41L5649

SIGC02 Control Panel (NB1) to

Tower Card (CB1)

41L5517

Table 73. FC 5078, 0578 I/O Tower Power Cables

Name Description Part Number

PWRC01 Power Distribution

Backplane (PB1) to AMDs

(B01 and B02)

41L5652

PWRC02 Power Distribution

Backplane (PB1) to SPCN

connector

41L5650

PWRC03 SPCN connector to Tower

Card (CB1)

21P6096

PWRC04 Power Distribution

Backplane (PB1) to Power

connector

21P6094

PWRC05 Power connector to Tower

Card (CB1)

21P6095

Part Assemblies

Power and Signal Cables

802
