Table 43. FRU Locations and Failing Components Table for FC 9079 Base I/O Tower (continued)
Position FRU Name Possible Failing Component Type, CCIN, or
Part Number
(use the “Type,
Model, and Part
Number list”
on page 885 to
determine the
part number
when Type or
CCIN are
given.)
Removal and
Installation/Recovery
Procedure
C14 PCI Card The failing component is either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type,
Model, and
Part Number
list” on
page 885.
Go to “Models 840/SB3, FC
8079 (lower half), FC 9079
Cards — Concurrent” on
page 678.
C15 PCI Card The failing component is either an:
1. IOP
2. IOA
1. 2842 or 2843
2. See “Type,
Model, and
Part Number
list” on
page 885.
Go to “Models 840/SB3, FC
8079 (lower half), FC 9079
Cards — Concurrent” on
page 678.
CB1 Tower Card
v SPCN Card
v Tower Card
v Service Processor
v Multi-adapter Bridge (All)
28AA Go to “FC 5074/5079, FC
9079 – Tower Card – CB1”
on page 635.
A01 AC Input /
Charger
AC Module/Charger
v 97H7316 –
Single Line
Cord
Go to “FC 5074, FC 5079, FC
9079 (With Single Line
Cord) – AC Charger – A01”
on page 618.
AC Module AC Module 21P6347 – Dual
Line Cord
Go to “Model 830 FC 9074,
Model 840 FC 9079/8079
(With Dual Line Cords) –
AC Module (A01, A02)” on
page 654.
A02 AC Module AC Module 21P6347 – Dual
Line Cord
Go to “Model 830 FC 9074,
Model 840 FC 9079/8079
(With Dual Line Cords) –
AC Module (A01, A02)” on
page 654.
P01 – P03 Power
Supply
Power Supply 90H6629 –
Single Line
Cord
Go to “FC 9074, FC 9079, FC
5074/5079 – Power Supply –
P01, P02, and P03” on
page 632.
P01 – P02 Power
Supply
Power Supply 21P5383 – Dual
Line Cord
Go to “FC 9074, FC 9079, FC
5074/5079 – Power Supply –
P01, P02, and P03” on
page 632.
PB1 Power Board Power Board 24L0891 Go to “FC 5074, FC 5079, FC
9079 – Power Distribution
Board – PB1” on page 631.
Locations and Addresses
728
iSeries Model 830, 840, SB2, and SB3 Problem Analysis, Repair and Parts V5R1
