Table 54. Models 830, SB2 System Unit with FC 9074 – Single Line Cord Signal Cables
Name Description Part Number
SIG60 IOA in Tower Card (CB1) to
Device Board 3 (DB3)
97H7481
SIG61 IOA in Tower Card (CB1) to
Device Board 2 (DB2)
44L0070
SIG62 IOA in Tower Card (CB1) to
Device Board 1 (DB1)
97H7484
SIG63 Control Panel (NB1) to
Device Board 3 (DB3)
24L1752
SIG64 Tower Card (CB1) to Power
Distribution Board (PB1 -
includes P/N 97H7476,
97H7477, 97H7607) (part of
the Tower Card FRU
assembly)
24L0843
SIGC65 Control Panel (NB1) to CEC
interface
97H7327
SIGC66 CEC interface to CEC
backplane interface, to Power
Supplies (PP1 & PP2), and to
AMD (BP1 & BP2)
04N3037
SIGC67 CEC cage assembly to CEC
bulkhead
97H7472
SIGC68 Part of backplane FRU
assembly (MB1) (internal
cable)
97H7601
SIGC69 Part of backplane FRU
assembly (MB1) (internal
cable)
97H7603
SIGC70 Part of backplane FRU
assembly (MB1) (internal
cable)
97H7600
SIGC71 JTAG-A (external cable)
Tower card (CB1) to CEC
cage assembly.
97H7486
SIGC72 V/S COMM (external cable)
Tower card (CB1) to CEC
cage assembly.
44L0007
SIGC73 HSL (C08) to backplane FRU
assembly MB1 cable
97H7326
Table 55. Models 830, SB2 System Unit with FC 9074 – Single Line Cord Power Cables
Name Description Part Number
PWR60 Power Distribution Board
(PB1) to Device Board 3
(DB3)
24L1886
PWR61 to PWR64 Power Distribution Board
(PB1) to Device Board 2
(DB2)
97H7483
Power and Signal Cables
Chapter 5. Locations, Addresses, and Part Listings 781
