Table 57. Models 830, SB2 System Unit with FC 9074 – Dual Line Cord Power

Cables (continued)

Name Description Part Number

PWR65 Power Distribution Board

(PB1) to Device Board 2

(DB2)

97H7544

PWR66 to PWR69 Power Distribution Board

(PB1) to Device Board 2

(DB2)

97H7543

SIG71 Tower Card (CB1) to CEC

Cage Assembly

97H7486

SIG72 Tower Card (CB1) to CEC

Cage Assembly

44L0007

PWR70 Power Distribution Board

(PB1) to Device Board 1

(DB1)

97H7544

PWR71 to PWR74 Power Distribution Board

(PB1) to Device Board 1

(DB1)

97H7543

PWR75 Power Distribution Board

(PB1) to AMDs (B01 and

B02)

97H7475

PWR77 AC Input (A01) to Power

Supply 1 (P01)

04N2181

PWR78 AC Input (A02) to Power

Supply 2 (P02)

04N2181

PWRC80 Power Distribution Board

(PB1) to CEC interface

97H7479

PWRC81 AC Input (A01) to Processor

Power (PP1)

04N6134

PWRC82 AC Input (A02) to Processor

Power (PP2)

04N6134

Power and Signal Cables

Chapter 5. Locations, Addresses, and Part Listings 785
