Asm–

Index

Part

Number Units Description

3–15 24L0972 1 CEC Cage Asm.

–16 1621811 6 Screw, M4 (10mm)

–17 NONUM 1 System Unit Backplane/Stiffener Asm. (MB1)

–18 24L0906 6 Screw

Assembly 3: (continued)

Chapter 5. Locations, Addresses, and Part Listings 819
