4–1 NONUM 1 Control Panel Cover

–2 AR 1 Processor Capacity Card (FC 9074 Only) (slot A)

See the “Type, Model, and Part Number list” on page 885.

–3 AR 1 Interactive Card (FC 9074 Only) (slot B)

See the “Type, Model, and Part Number list” on page 885.

–4 NONUM 1 Key Asm.

Assembly 4: (continued)

Chapter 5. Locations, Addresses, and Part Listings 825
