Asm–
Index
Part
Number Units Description
6–1 23L3367 1 EMC access plate, Front Cage
–2 1621811 3 Screw, M4 (10mm)
–3 23L3365 1 EMC access plate, Front Cage
–4 1621811 3 Screw, M4 (10mm)
–5 23L3428 1 EMC Bracket, Top
–6 1621811 6 Screw, M4 (10mm)
–7 23L3433 1 EMC Bracket, Right
–8 1621811 15 Screw, M4 (10mm)
–9 NONUM 1 Front Cage/Backplane Asm
See 836.
–10 1621811 12 Screw, M4 (10mm)
–11 23L3469 1 Control Panel Asm, Processor Tower
See “Assembly 8: Models 840 and SB3 – Control Panel, Processor Tower” on
page 838.
–12 1621811 2 Screw, M4 (10mm)
Assembly 6: (continued)
Chapter 5. Locations, Addresses, and Part Listings 829
