Asm–

Index

Part

Number Units Description

7–1 23L3366 1 EMC Access Plate

–2 1621811 2 Screw, M4 (10mm)

–3 23L3427 1 EMC Bracket, Left

–4 1621811 17 Screw, M4 (10mm)

–5 23L3428 1 EMC Bracket, Top

–6 1621811 5 Screw, M4 (10mm)

–7 23L3385 1 Cage Asm. Rear

–8 1621811 13 Screw, M4 (10mm)

–9 1624766 8 Screw

–10 23L3447 1 EMC Access Plate

–11 1621811 5 Screw, M4 (10mm)

–12 23L3368 1 EMC Access Plate

–13 1621811 3 Screw, M4 (10mm)

Assembly 7: (continued)

Chapter 5. Locations, Addresses, and Part Listings 833
