Asm–
Index
Part
Number Units Description
10–5 NONUM 1 Removable Media Cage Assembly
–6 1621811 2 Screw, M4 (10mm)
–7 1621817 2 Screw
–8 24L1067 1 Center Support Bracket
–9 1621811 2 Screw, M4 (10mm)
–10 NONUM AR 5 Disk Unit Cage Assembly
–11 1621811 12 Screw, M4 (10mm)
–12 1621817 6 Screw
–13 AR Disk Unit Assembly
See “Type, Model, and Part Number list” on page 885.
Assembly 10: (continued)
Chapter 5. Locations, Addresses, and Part Listings 845
