Asm–

Index

Part

Number Units Description

10–33 24L0926 1 PCI Card Cage Assembly (For FC 9079)

–34 1621811 6 Screw, M4 (10mm)

–35 24L0891 1 Power Board/Stiff. Asm. (PB1)

–36 1621816 6 Screw

–37 16G8095 1 TOD Battery

Assembly 10: (continued)

Chapter 5. Locations, Addresses, and Part Listings 851
