Asm–

Index

Part

Number Units Description

13–1 24L1630 1 Cover, Top

–2 75G2878 2 Screw, M3.5 x 8mm

–3 24L1652 1 Cover, Rear

–4 24L1632 1 Cover, Side

–5 24L1946 2 Thumbscrew

–6 24L1654 1 Cover, Front

–7 24L1632 1 Cover, Side

–8 75G2878 2 Screw, M3.5 x 8mm

Assembly 13: (continued)

Chapter 5. Locations, Addresses, and Part Listings 865
