Asm–
Index
Part
Number Units Description
14–1 24L1592 1 Op Panel
–2 24L1730 2 AMD Asm.
–3 NONUM 1 Cage Asm., Disk Unit
–4 75G2878 4 Screw, M3.5 x 8mm
–4A 04N3392 2 Screw, M3.5 x 35mm
–5 24L1827 1 EMC Shield, Disk Unit
–5A NONUM AR Disk Unit Asm.
See “Type, Model, and Part Number list” on page 885.
–6 21P6417 AR Power Supply
See “Type, Model, and Part Number list” on page 885.
Assembly 14: (continued)
Chapter 5. Locations, Addresses, and Part Listings 867
