4.3.8 Get/Set Sensor and Source Parameters
Get Command = <CommandID><Sensor|Source><?><Space><Parameter>
Get Response = <A><String|Value>
Set Command = <CommandID><Sensor|Source><Space><Parameter>
<Comma><String|Value>
Set Response = <A>
Table 4-9 Get/Set sensor and source parameters
Cmd ID Description Parameters
HA Gets/Sets the parameters of each
of the 2 or 4 sensors.
1 Crystal Tooling
2 Number of Positions
3Shutter
4 Shutter Delay (ms)
5 Control Type
6Drive Type
7 Feedback Type
8 Indexer Delay
9 Current Crystal Position
HB Gets/Sets the parameters of each
of the 2 or 4 sources.
1 Voltage Scale
2 Number of Positions
3Shutter
4 Shutter Delay (ms)
5 Control Type
6Drive Type
7 Feedback Type
8 Indexer Delay
9 Current Pocket Position
HC Gets the status flags for each of the
2 or 4 sensors.
1 Dual crystal has switched
2 Backup crystal switch has begun
3 Backup crystal switch is done
4 Sensor is disabled
5 Original crystal has failed
6 Sensor is currently in use
7 Next crystal move complete
8 Sensor initiated time power
9 Sensor initiate halted
HD Gets the status flags for each of the
2 or 4 sources.
1 Source is currently in use
HE Gets/Sets the IO mappings of each
of the 2 or 4 sensors.
1 Input Map
2Relay Map
HF Gets/Sets the IO mappings of each
of the 2 or 4 sources.
1 Input Map
2Relay Map
