SQC-310 Operating Manual
SQC-310 configuration includes:
Thin Film Instrument and Sensor Manuals CD containing SQC-310 software,
SQC-310 Operating Manual, and sensor operating manuals.
25-pin female high-density solder cup D-sub connector (PN 051-1846) and
connector housing (PN 051-1794). One of each included for a 2 channel
standard configuration. Two of each included if 4 channel option is selected.
Power Cord - Based on origin of order (universal power supply)
Power Cord 120 V (PN 803081)
Power Cord 230 V (PN 803146)
Power Cord UK (PN 803301)
RS-232 Cable (PN 068-0464)
USB Cable (PN 068-0472), if USB option is chosen
Ethernet Cable (PN 068-0478), if Ethernet option is chosen
1.6.2 Accessories
1.6.2.1 Cables and Oscillator Kits
Oscillator Kit (3.0 m (10 ft.) cable) . . . . . . . . . . . . . . PN 783-500-109-10
Oscillator Kit (7.6 m (25 ft.) cable) . . . . . . . . . . . . . . PN 783-500-109-25
Oscillator Kit (15.2 m (50 ft.) cable) . . . . . . . . . . . . . PN 783-500-109-50
Oscillator Kit (22.8 m (75 ft.) cable) . . . . . . . . . . . . . PN 783-500-109-75
NOTE: One oscillator kit is required for each crystal sensor that will be connected
to the SQC-310. Each oscillator kit includes:
15.2 cm (6 in.) BNC cable (PN 782-902-011) - Cable from the oscillator to
the feedthrough
OSC-100A Oscillator (PN 783-500-013)
BNC Interconnect Cable (PN 782-902-012-XX) - Cable from the oscillator
to SQC-310.
The electrical distance from the oscillator to the crystal
must not exceed 102 cm (40 in.)
