On the SQC-310 System Menu >> Sensors & Sources (see section 3.12.3 on
page 3-36) set up the source with:
 Number of Positions: 8
 Control Type: BCD
 Feedback Type: In Position
 Indexer Delay: 5 seconds
2.9.2 Individual (Binary - as defined by CI-100) I/O Setup
To use Individual wiring between CI-100 and SQC-310 for a four pocket crucible:
SQC-310
CI-100 Binary I/O
Pin 1,3,5,14,24 ---------------- Pin 1, 2 Common
Pin 16 ------------<-------------- Pin 3 OutX Pocket Ready
Pin 15 ------------>-------------- Pin 4 OutX Pocket 1
Pin 2 -------------->-------------- Pin 6 OutX Pocket 2
Pin 4 -------------->-------------- Pin 8 OutX Pocket 3
Pin 6 -------------->-------------- Pin 10 OutX Pocket 4
On the CI-100 rear panel, set Select Switch #5 down.
On the SQC-310 System Menu >> Sensors & Sources (see section 3.12.3 on
page 3-36) set up the source with:
 Number of Positions: 4
 Control Type: Individual
 Feedback Type: In Position
 Indexer Delay: 5 seconds
