2 - 1
PN 074-550-P1D
SQC-310 Operating Manual
Chapter 2
Installation
2.1 Introduction
This chapter provides information for the necessary connections and user
interfaces for SQC-310. (See Table 2-1 for connection and installation
requirements.)
Care should be exercised to route SQC-310 cables as
far as is practical from other cables that carry high
voltages or generate noise. This includes other line
voltage cables, wires to heaters that are SCR-controlled,
and cables to source power supplies that may conduct
high transient currents during arc down conditions.
To maintain proper SQC-310 performance, use only the
15.2 cm (6 in.) BNC cable, included in the oscillator kit, to
connect the oscillator to the crystal sensor. The
in-vacuum cable or electrical conduit tube should not
exceed 78.1 cm (30.75 in.).
