2 - 12
PN 074-550-P1D
SQC-310 Operating Manual
NOTE: Relays 9 to 16 and inputs 9 to 16 use the same connector pins as found
on the second rear panel I/O connector (if available) in the same
sequential order.
2.9 Interfacing SQC-310 to CI-100 Crucible Indexer
This section assumes an understanding of the setup and operations for SQC-310
and CI-100 Crucible Indexer. See Chapter 3, Operation for more SQC-310
operations information.
2.9.1 BCD I/O Setup
BCD wiring is suggested over Individual I/O wiring because it uses fewer relays.
The wiring below interfaces the SQC-310 I/O connector to the CI-100 BCD I/O
connector for controlling an 8 pocket source.
SQC-310
CI-100 BCD I/O
Pin 14------------->-------------- Pin 1 OutX Pocket Bit1
Pin 1 -------------->-------------- Pin 2 OutX Pocket Bit2
Pin 3 -------------->-------------- Pin 7 OutX Pocket Bit3
Pin 16 ------------<-------------- Pin 5 OutX Pocket Ready
Pin 15,2,4------------------------ Pin 6 Common
Short Pin 3 to Pin 9 Interlock
Short Pin 4 to Pin 8 Pocket Ready A
On the CI-100 rear panel: set Select Switch #5 up and #7 down.
Table 2-5 I/O connector wiring
Relay Pins Input Pins
Relay 1 14,15 Input 1 16
Relay 2 1,2 Input 2 17
Relay 3 3,4 Input 3 18
Relay 4 5,6 Input 4 19
Relay 5 7,8 Input 5 20
Relay 6 9,10 Input 6 21
Relay 7 11,12 Input 7 22
Relay 8 13,25 Input 8 23
Ground 24
