SQC-310 Operating Manual
5.5.2 Film Menu
In the Instrument window toolbar, click Edit >> Films... to display the Film Edit
window to assign materials stored in the database to films (50 films maximum)
which are used to define process layers (see Figure 5-6). Alternatively, on the
Process Tree, click the + next to a process name to display the layers for that
process. Click the + next to a layer name to display the film for that layer.
Double-click the film to open the Film menu.
NOTE: Any changes to a film will apply to every layer, in every process where that
film is used.
Figure 5-6 Film menu
Film . . . . . . . . . . . . . . . . . . . . . . . . . Selects the film to be edited. Click on the film
dropdown box to edit the film name.
Material . . . . . . . . . . . . . . . . . . . . . . List of available database materials. The
material displayed/selected is designated for
the film currently displayed.
For complete list of parameters, definitions, usage, and the range of acceptable
values for each parameter refer to section 3.11, Film Edit Menu, on page 3-18.
OK . . . . . . . . . . . . . . . . . . . . . . . . . . Closes the Film menu and saves the data to
memory. Be sure to select File >> Save
Database or Save As Database to save any
changes to the database (.mdb) file.
