SQC-310 Operating Manual
Insert Normal or Insert CoDep inserts layers above the selected layer. That is, the
inserted layer will have the same number as the selected layer, and the selected
layer will move down one layer.
HINT: When building a process it is easiest to add a test layer and insert new
layers above that layer. When the process is complete, delete the test layer.
NOTE: Each CoDep layer (SQC-310C only) must be assigned to a different output
and sensor.
A warning message is displayed if there is a conflict. Select each CoDep
layer, press Edit, and assign unique sensors and outputs.
3.10 Film Menus
The Film menus allows for the entering and editing of the parameters that regulate
the deposition of each film. These parameters apply any time this film is used (in
any process). Rotate the control knob to scroll through and select films.
Figure 3-12 Film Select menu
Table 3-8 Film Select menu buttons
Main Screen Returns to the Main menu.
Edit... Displays the Film Edit menu for the selected film.
Edit Name... Displays the Character Entry screen to edit the selected film name.
