Ballout and Package Information
R
Intel
®
82925X/82925XE MCH Datasheet 201
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SDQS_A6# AA35
SDQS_A7 U34
SDQS_A7# U35
SDQS_A8
(82925X)
RSV (82925XE)
V30
SDQS_A8#
(82925X)
RSV (82925XE)
U30
SDQS_B0 AH8
SDQS_B0# AH9
SDQS_B1 AM5
SDQS_B1# AL5
SDQS_B2 AH13
SDQS_B2# AG14
SDQS_B3 AG20
SDQS_B3# AF20
SDQS_B4 AH25
SDQS_B4# AG26
SDQS_B5 AH28
SDQS_B5# AH30
SDQS_B6 AB31
SDQS_B6# AC30
SDQS_B7 W27
SDQS_B7# Y28
SDQS_B8
(82925X)
RSV (82925XE)
AK21
SDQS_B8#
(82925X)
RSV (82925XE)
AJ21
SMA_A0 AN26
SMA_A1 AP25
SMA_A2 AN25
SMA_A3 AR24
SMA_A4 AP23
SMA_A5 AN22
SMA_A6 AR23
SMA_A7 AN21
SMA_A8 AN23
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SMA_A9 AP22
SMA_A10 AP26
SMA_A11 AP21
SMA_A12 AN20
SMA_A13 AN30
SMA_B0 AN15
SMA_B1 AR15
SMA_B2 AN14
SMA_B3 AP14
SMA_B4 AN13
SMA_B5 AN11
SMA_B6 AP13
SMA_B7 AR11
SMA_B8 AR12
SMA_B9 AP11
SMA_B10 AP15
SMA_B11 AP10
SMA_B12 AN10
SMA_B13 AM34
SMSLEWIN0 AJ12
SMSLEWIN1 AF9
SMSLEWOUT0 AK12
SMSLEWOUT1 AE10
SOCOMP0 AF5
SOCOMP1 AE5
SODT_A0 AP30
SODT_A1 AP32
SODT_A2 AN29
SODT_A3 AN32
SODT_B0 AN34
SODT_B1 AL34
SODT_B2 AL35
SODT_B3 AL33
SRAS_A# AP27
SRAS_B# AN17
SRCOMP0 AG4
SRCOMP1 AG8
SVREF0 AE7
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SVREF1 AE8
SWE_A# AN28
SWE_B# AP17
VCC R16
VCC R18
VCC R20
VCC R22
VCC R23
VCC T13
VCC T14
VCC T15
VCC T16
VCC T17
VCC T19
VCC T20
VCC T21
VCC T23
VCC T24
VCC U13
VCC U14
VCC U16
VCC U18
VCC U20
VCC U22
VCC U24
VCC V13
VCC V14
VCC V15
VCC V17
VCC V19
VCC V21
VCC V23
VCC V24
VCC W13
VCC W14
VCC W16
VCC W18
VCC W20
