Ballout and Package Information
R
200 Intel
®
82925X/82925XE MCH Datasheet
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SDQ_A27 AH17
SDQ_A28 AE15
SDQ_A29 AD17
SDQ_A30 AK16
SDQ_A31 AJ17
SDQ_A32 AK29
SDQ_A33 AK31
SDQ_A34 AH27
SDQ_A35 AD27
SDQ_A36 AL30
SDQ_A37 AL31
SDQ_A38 AG27
SDQ_A39 AF28
SDQ_A40 AH34
SDQ_A41 AH35
SDQ_A42 AF33
SDQ_A43 AE33
SDQ_A44 AK34
SDQ_A45 AJ34
SDQ_A46 AG32
SDQ_A47 AF34
SDQ_A48 AD31
SDQ_A49 AD35
SDQ_A50 Y33
SDQ_A51 W34
SDQ_A52 AE35
SDQ_A53 AE34
SDQ_A54 AA32
SDQ_A55 Y35
SDQ_A56 V34
SDQ_A57 V33
SDQ_A58 R32
SDQ_A59 R34
SDQ_A60 W35
SDQ_A61 W33
SDQ_A62 T33
SDQ_A63 T35
SDQ_B00 AG11
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SDQ_B01 AG10
SDQ_B02 AJ7
SDQ_B03 AJ6
SDQ_B04 AE11
SDQ_B05 AF11
SDQ_B06 AJ8
SDQ_B07 AH7
SDQ_B08 AK10
SDQ_B09 AL4
SDQ_B10 AL8
SDQ_B11 AF12
SDQ_B12 AH4
SDQ_B13 AJ5
SDQ_B14 AL6
SDQ_B15 AN6
SDQ_B16 AF13
SDQ_B17 AD14
SDQ_B18 AF14
SDQ_B19 AE14
SDQ_B20 AD12
SDQ_B21 AE13
SDQ_B22 AK13
SDQ_B23 AL14
SDQ_B24 AD18
SDQ_B25 AE19
SDQ_B26 AL18
SDQ_B27 AK19
SDQ_B28 AF15
SDQ_B29 AD15
SDQ_B30 AH19
SDQ_B31 AH21
SDQ_B32 AF24
SDQ_B33 AG24
SDQ_B34 AL26
SDQ_B35 AJ26
SDQ_B36 AF23
SDQ_B37 AD23
SDQ_B38 AL25
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SDQ_B39 AJ25
SDQ_B40 AK32
SDQ_B41 AJ31
SDQ_B42 AG31
SDQ_B43 AF30
SDQ_B44 AJ29
SDQ_B45 AK33
SDQ_B46 AG30
SDQ_B47 AG28
SDQ_B48 AF27
SDQ_B49 AE27
SDQ_B50 AC26
SDQ_B51 AB26
SDQ_B52 AE31
SDQ_B53 AE29
SDQ_B54 AC28
SDQ_B55 AB27
SDQ_B56 AA28
SDQ_B57 W29
SDQ_B58 V28
SDQ_B59 V29
SDQ_B60 Y26
SDQ_B61 AA29
SDQ_B62 W26
SDQ_B63 U26
SDQS_A0 AG1
SDQS_A0# AG2
SDQS_A1 AL3
SDQS_A1# AL2
SDQS_A2 AP7
SDQS_A2# AN7
SDQS_A3 AH16
SDQS_A3# AG17
SDQS_A4 AK27
SDQS_A4# AJ28
SDQS_A5 AG35
SDQS_A5# AG33
SDQS_A6 AA34
