Ballout and Package Information
R
Intel
®
82925X/82925XE MCH Datasheet 199
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SCB_A0 (82925X)
RSV (82925XE)
V32
SCB_A1 (82925X)
RSV (82925XE)
V31
SCB_A2 (82925X)
RSV (82925XE)
AA31
SCB_A3 (82925X)
RSV (82925XE)
AA30
SCB_A4 (82925X)
RSV (82925XE)
R30
SCB_A5 (82925X)
RSV (82925XE)
R31
SCB_A6 (82925X)
RSV (82925XE)
Y30
SCB_A7 (82925X)
RSV (82925XE)
AB29
SCB_B0 (82925X)
RSV (82925XE)
AJ20
SCB_B1 (82925X)
RSV (82925XE)
AJ18
SCB_B2 (82925X)
RSV (82925XE)
AJ23
SCB_B3 (82925X)
RSV (82925XE)
AJ24
SCB_B4 (82925X)
RSV (82925XE)
AL20
SCB_B5 (82925X)
RSV (82925XE)
AK18
SCB_B6 (82925X)
RSV (82925XE)
AL21
SCB_B7 (82925X)
RSV (82925XE)
AL22
SCKE_A0 AP19
SCKE_A1 AN19
SCKE_A2 AN18
SCKE_A3 AR19
SCKE_B0 AR9
SCKE_B1 AP9
SCKE_B2 AR8
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SCKE_B3 AN8
SCLK_A0 AL29
SCLK_A0# AM30
SCLK_A1 AN2
SCLK_A1# AN3
SCLK_A2 AC34
SCLK_A2# AC35
SCLK_A3 AL28
SCLK_A3# AK28
SCLK_A4 AM3
SCLK_A4# AM2
SCLK_A5 AC33
SCLK_A5# AB34
SCLK_B0 AH23
SCLK_B0# AG23
SCLK_B1 AK9
SCLK_B1# AL9
SCLK_B2 AE26
SCLK_B2# AE25
SCLK_B3 AL23
SCLK_B3# AK22
SCLK_B4 AJ11
SCLK_B4# AL11
SCLK_B5 AD28
SCLK_B5# AD29
SCS_A0# AR29
SCS_A1# AN31
SCS_A2# AR28
SCS_A3# AP31
SCS_B0# AP33
SCS_B1# AM33
SCS_B2# AN33
SCS_B3# AP34
SDM_A0 AF2
SDM_A1 AL1
SDM_A2 AP6
SDM_A3 AF17
SDM_A4 AJ33
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
SDM_A5 AG34
SDM_A6 AA33
SDM_A7 U33
SDM_B0 AH10
SDM_B1 AK5
SDM_B2 AH12
SDM_B3 AE20
SDM_B4 AF25
SDM_B5 AH31
SDM_B6 AD24
SDM_B7 W31
SDQ_A00 AE3
SDQ_A01 AF3
SDQ_A02 AH3
SDQ_A03 AJ2
SDQ_A04 AE2
SDQ_A05 AE1
SDQ_A06 AG3
SDQ_A07 AH2
SDQ_A08 AK2
SDQ_A09 AK3
SDQ_A10 AN4
SDQ_A11 AP4
SDQ_A12 AJ1
SDQ_A13 AJ3
SDQ_A14 AP2
SDQ_A15 AP3
SDQ_A16 AP5
SDQ_A17 AK7
SDQ_A18 AM9
SDQ_A19 AL7
SDQ_A20 AR5
SDQ_A21 AN5
SDQ_A22 AM7
SDQ_A23 AM8
SDQ_A24 AE17
SDQ_A25 AF16
SDQ_A26 AL17
