UC: Frame must be unicast.
Specific: If you want to filter a specific destination MAC address with
this ACE, choose this value. A field for entering a DMAC value appears.
• DMAC Value
When "Specific" is selected for the DMAC filter, you can enter a
specific destination MAC address. The legal format is
"xx-xx-xx-xx-xx-xx". A frame that hits this ACE matches this DMAC
value.
VLAN Parameters
Object Description
• 802.1Q Tagged
Specify whether frames can hit the action according to the
802.1Q tagged. The allowed values are:
Any: Any value is allowed ("don't-care").
Enabled: Tagged frame only.
Disabled: Untagged frame only.
The default value is "Any".
• VLAN ID Filter
Specify the VLAN ID filter for this ACE.
Any: No VLAN ID filter is specified. (VLAN ID filter status is
"don't-care".)
Specific: If you want to filter a specific VLAN ID with this ACE,
choose this value. A field for entering a VLAN ID number appears.
• VLAN ID
When "Specific" is selected for the VLAN ID filter, you can enter a
specific VLAN ID number. The allowed range is 1 to 4095. A frame
that hits this ACE matches this VLAN ID value.
• Tag Priority
Specify the tag priority for this ACE. A frame that hits this ACE
matches this tag priority. The allowed number range is 0 to 7. The
value Any means that no tag priority is specified (tag priority is
"don't-care".)
ARP Parameters
The ARP parameters can be configured when Frame Type "ARP" is selected.
Object Description
• ARP/RARP
Specify the available ARP/RARP opcode (OP) flag for this ACE.
Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
ARP: Frame must have ARP/RARP opcode set to ARP.
RARP: Frame must have ARP/RARP opcode set to RARP.
Other: Frame has unknown ARP/RARP Opcode flag.
• Request/Reply
Specify the available ARP/RARP opcode (OP) flag for this ACE.
