IFS NS3502-8P-2S User Manual
Any: No ARP/RARP OP flag is specified. (OP is "don't-care".)
Request: Frame must have ARP Request or RARP Request OP flag
set.
Reply: Frame must have ARP Reply or RARP Reply OP flag.
• Sender IP Filter
Specify the sender IP filter for this ACE.
Any: No sender IP filter is specified. (Sender IP filter is
"don't-care".)
Host: Sender IP filter is set to Host. Specify the sender IP address
in the SIP Address field that appears.
Network: Sender IP filter is set to Network. Specify the sender IP
address and sender IP mask in the SIP Address and SIP Mask
fields that appear.
• Sender IP Address
When "Host" or "Network" is selected for the sender IP filter, you
can enter a specific sender IP address in dotted decimal notation.
• Sender IP Mask
When "Network"
is selected for the sender IP filter, you can enter
a specific sender IP mask in dotted decimal notation.
• Target IP Filter
Specify the target IP filter for this specific ACE.
Any: No target IP filter is specified. (Target IP filter is
"don't-care".)
Host: Target IP filter is set to Host. Specify the target IP address
in the Target IP Address field that appears.
Network: Target IP filter is set to Network. Specify the target IP
address and target IP mask in the Target IP Address and Target IP
Mask fields that appear.
• Target IP Address
When "Host" or "Network" is selected for the target IP filter, you
can enter a specific target IP address in dotted decimal notation.
• Target IP Mask
When "Network" is selected for the target IP filter, you can enter
a specific target IP mask in dotted decimal notation.
• ARP SMAC Match
Specify whether frames can hit the action according to their
sender hardware address field (SHA) settings.
0: ARP frames where SHA is not equal to the SMAC address.
1: ARP frames where SHA is equal to the SMAC address.
: Any value is allowed ("don't-care").
• RARP SMAC Match
Specify whether frames can hit the action according to their
target hardware address field (THA) settings.
0: RARP frames where THA is not equal to the SMAC address.
1: RARP frames where THA is equal to the SMAC address.
Any: Any value is allowed ("don't-care").
• IP/Ethernet Length
Specify whether frames can hit the action according to their
ARP/RARP hardware address length (HLN) and protocol address
