• TCP/UDP Source
Range
When "Range" is selected for the TCP/UDP source filter, you can
enter a specific TCP/UDP source range value. The allowed range
is 0 to 65535. A frame that hits this ACE matches this TCP/UDP
source value.
• TCP/UDP
Destination Filter
Specify the TCP/UDP destination filter for this ACE.
Any: No TCP/UDP destination filter is specified (TCP/UDP
destination filter status is "don't-care").
Specific: If you want to filter a specific TCP/UDP destination
filter with this ACE, you can enter a specific TCP/UDP destination
value. A field for entering a TCP/UDP destination value appears.
Range: If you want to filter a specific range TCP/UDP destination
filter with this ACE, you can enter a specific TCP/UDP destination
range value. A field for entering a TCP/UDP destination value
appears.
• TCP/UDP
Destination
Number
When "Specific" is selected for the TCP/UDP destination filter,
you can enter a specific TCP/UDP destination value. The allowed
range is 0 to 65535. A frame that hits this ACE matches this
TCP/UDP destination value.
• TCP/UDP
Destination Range
When "Range" is selected for the TCP/UDP destination filter, you
can enter a specific TCP/UDP destination range value. The
allowed range is 0 to 65535. A frame that hits this ACE matches
this TCP/UDP destination value.
• TCP FIN
Specify the TCP "No more data from sender" (FIN) value for this
ACE.
0: TCP frames where the FIN field is set must not be able to
match this entry.
1: TCP frames where the FIN field is set must be able to match
this entry.
Any: Any value is allowed ("don't-care").
• TCP SYN
Specify the TCP "Synchronize sequence numbers" (SYN) value for
this ACE.
0: TCP frames where the SYN field is set must not be able to
match this entry.
1: TCP frames where the SYN field is set must be able to match
this entry.
