this entry.
Any: Any value is allowed ("don't-care").
• TCP PSH
Specify the TCP "Push Function" (PSH) value for this ACE.
0: TCP frames where the PSH field is set must not be able to
match this entry.
1: TCP frames where the PSH field is set must be able to match
this entry.
Any
: Any value is allowed ("don't-care").
• TCP ACK
Specify the TCP "Acknowledgment field significant" (ACK) value
for this ACE.
0: TCP frames where the ACK field is set must not be able to
match this entry.
1: TCP frames where the ACK field is set must be able to match
this entry.
Any: Any value is allowed ("don't-care").
• TCP URG
Specify the TCP "Urgent Pointer field significant" (URG) value for
this ACE.
0: TCP frames where the URG field is set must not be able to
match this entry.
1: TCP frames where the URG field is set must be able to match
this entry.
Any
: Any value is allowed ("don't-care").
 Ethernet Type Parameters
The Ethernet Type parameters can be configured when Frame Type "Ethernet Type" is selected.
Object Description
• EtherType Filter
Specify the Ethernet type filter for this ACE.
Any: No EtherType filter is specified (EtherType filter status is
"don't-care").
Specific: If you want to filter a specific EtherType filter with this
ACE, you can enter a specific EtherType value. A field for entering
an EtherType value appears.
• Ethernet Type
Value
When "Specific" is selected for the EtherType filter, you can enter
a specific EtherType value. The allowed range is 0x600 to 0xFFFF
but excluding 0x800(IPv4), 0x806(ARP) and 0x86DD (IPv6). A
frame that hits this ACE matches this EtherType value.
Buttons
: Click to save changes.
