GAPS - User Guide
E.4 Four Transponders - Three Interrogation Codes
TP Interr. code Reply code TaT Rep. factor
TP1 1 22 90 ms x1
TP2 1 23 90 ms x1
TP3 2 22 90 ms x1
TP4 3 22 90 ms x1
Distance max (m) < 682 < 1432 < 2182 < 2932 < 3682 < 4432
GAPS recurrence 1 s 2 s 3 s 4 s 5 s 6 s
Blanking time TP1 2.8 s 5.8 s 8.8 s 11.8 s 14.8 s 17.8 s
Blanking time TP2 2.8 s 5.8 s 8.8 s 11.8 s 14.8 s 17.8 s
Blanking time TP3 2.8 s 5.8 s 8.8 s 11.8 s 14.8 s 17.8 s
Blanking time TP4 2.8 s 5.8 s 8.8 s 11.8 s 14.8 s 17.8 s
MU-GAPS-AN-005-H - November 2019 173
