Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 7: Command reference
2651A-901-01 Rev. A / March 2011 7-147
Example
format.asciiprecision = 10
x = 2.54
printnumber(x)
format.asciiprecision = 3
printnumber(x, 2.54321, 3.1)
Output:
2.540000000e+00
2.54e+00, 2.54e+00, 3.10e+00
Also see
format.asciiprecision (on page 7-86)
format.byteorder
(on page 7-87)
format.data
(on page 7-87)
print()
(on page 7-144)
printbuffer() (on page 7-145)
PulseIMeasureV()
This KIPulse factory script (on page 5-23) function performs a specified number of pulse I, measure V cycles.
Type TSP-Link accessible
Affected by Where saved Default value
Function No
Usage
PulseIMeasureV(smu, bias, level, ton, toff, points)
smu
System SourceMeter
®
instrument channel (set to smua)
bias
Bias level in amperes
level
Pulse level in amperes
ton
Pulse on time in seconds
toff
Pulse off time in seconds
points
Number of pulse-measure cycles
Details
Data for pulsed voltage measurements, current levels, and timestamps are stored in smuX.nvbuffer1.
If any parameters are omitted or nil, the operator will be prompted to enter them using the front panel.
Performs a specified number of pulse I, measure V cycles:
1. Sets the smu to output bias amperes and dwell for toff seconds.
2. Sets the smu to output level amperes and dwell for ton seconds.
3. Performs voltage measurement with source at level amperes.
4. Sets the smu to output bias amperes for toff seconds.
5. Repeats steps 2 through 4 for all remaining points pulse-measure cycles.
