Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 7: Command reference
2651A-901-01 Rev. A / March 2011 7-295
status.operation.sweeping.*
This attribute contains the operation status sweeping summary register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 2 (All bits set)
Usage
operationRegister = status.operation.sweeping.condition
operationRegister = status.operation.sweeping.enable
operationRegister = status.operation.sweeping.event
operationRegister = status.operation.sweeping.ntr
operationRegister = status.operation.sweeping.ptr
status.operation.sweeping.enable = operationRegister
status.operation.sweeping.ntr = operationRegister
status.operation.sweeping.ptr = operationRegister
operationRegister
The operation status sweeping summary register's status. A zero (0) indicates no
bits set (also send 0 to clear all bits); the only valid value other than zero (0) is 2
Details
These attributes are used to read or write to the operation status sweeping summary registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are set. The
least significant bit of the binary number is Bit B0, and the most significant bit is Bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register sets
(on page E-
2) and Enable and transition registers
(on page E-18). The individual bits of this register have the following
meanings:
Bit Value Description
B0 Not used Not applicable.
B1
status.operation.sweeping.SMUA
Set bit indicates that SMU A is sweeping.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2-B5 Not used Not applicable.
In addition to the above constant, operationRegister can be set to the decimal equivalent of the bit to set.
Example
status.operation.sweeping.enable =
status.operation.sweeping.SMUA
Sets the SMUA bit of the operation
status sweeping summary enable
register using a constant.
Also see
Operation Status Registers (on page E-20)
status.operation.*
(on page 7-266)
