Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 1: Introduction
2651A-901-01 Rev. A / March 2011 1-3
• Internal memory stores five user setup options
• Dedicated reading buffers that can each store and recall over 140,000 measurements; additional
dynamic reading buffers can be created
• USB flash drive access for saving data buffers, test scripts, and user setups
• Digital I/O port: Allows the Model 2651A to control other devices
• Web-based characterization tool that provides easy access to data gathering, sweeping, and
pulsing features
• LXI
®
Class C compliance
• Embedded TSP scripting engine accessible from any host interface; responds to high-speed test
scripts comprised of instrument control commands
• TSP-Link
®
expansion bus that allows TSP-enabled instruments to trigger and communicate with
each other; advanced Test Script Processor (TSP
®
) scripting engine features enable parallel
script execution across the TSP-Link network
• Supports IEEE-488 (GPIB), RS-232, and local area network (LAN) connections
Additional source and measure features:
• Source ± DC voltage from 1 μV to 40.4 V
• Source ± DC current from 10 pA to 20.2 A
• Source ± pulse current up to 50 A
• Measure ± pulse current up to 50 A
• Measure ± DC voltage from 1 μV to 40.4 V
• Measure ± DC current from 10 pA to 20.2 A
General information
Displaying the instrument's serial number
To display the serial number on the front panel:
1. If the Model 2651A is in remote operation, press the EXIT (LOCAL) key once to place the
instrument in local operation.
2. Press the MENU key.
3. Use the navigation wheel
to scroll to the SYSTEM-INFO menu.
4. Press the ENTER key.
5. On the SYSTEM INFORMATION menu, scroll to the SERIAL# menu item and press the ENTER
key. The Model 2651A serial number is displayed.
