Keithley 2651A Reference Manual

Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-252 2651A-901-01 Rev. A / March 2011
Also see
Status model overview (on page E-4)
Status byte and service request (SRQ)
(on page E-14)
status.measurement.*
This attribute contains the measurement event register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 14,723 (all bits set)
Usage
measurementRegister = status.measurement.condition
measurementRegister = status.measurement.enable
measurementRegister = status.measurement.event
measurementRegister = status.measurement.ntr
measurementRegister = status.measurement.ptr
status.measurement.enable = measurementRegister
status.measurement.ntr = measurementRegister
status.measurement.ptr = measurementRegister
measurementRegister
The measurement event register's status. A zero (0) indicates no bits set (also
send 0 to clear all bits); other values indicate various bit settings.
Details
These attributes are used to read or write to the measurement event registers. Reading a status register returns
a value. The binary equivalent of the returned value indicates which register bits are set. The least significant bit
of the binary number is Bit B0, and the most significant bit is Bit B15. This attribute is used to read or write to the
measurement event registers. For example, assume value 257 is returned for the enable register. The binary
equivalent is 0000 0001 0000 0001. This value indicates that bit B0 (VLMT) and bit B8 (BAV) are set.
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
** > > > > > > > > > > > > > > *
0 0 0 0 0 0 0 1 0 0 0 0 0 0 0 1
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register sets
(on page E-
2) and Enable and transition registers
(on page E-18). The individual bits of this register have the following
meanings:
