Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 7: Command reference
2651A-901-01 Rev. A / March 2011 7-275
Also see
Operation Status Registers (on page E-20)
status.operation.instrument.digio.*
(on page 7-271)
status.operation.instrument.lan.*
This attribute contains the operation status LAN summary register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 1027 (All bits set)
Usage
operationRegister = status.operation.instrument.lan.condition
operationRegister = status.operation.instrument.lan.enable
operationRegister = status.operation.instrument.lan.event
operationRegister = status.operation.instrument.lan.ntr
operationRegister = status.operation.instrument.lan.ptr
status.operation.instrument.lan.enable = operationRegister
status.operation.instrument.lan.ntr = operationRegister
status.operation.instrument.lan.ptr = operationRegister
operationRegister
The operation status lan summary register's status. A zero (0) indicates no bits set
(also send 0 to clear all bits); other values indicate various bit settings.
Details
These attributes are used to read or write to the operation status LAN summary registers. The binary equivalent
of the value indicates which register bits are set. In the binary equivalent, the least significant bit is bit B0, and the
most significant bit is bit B15. For example, if a value of 1.02600e+03 (which is 1026) is read as the value of the
condition register, the binary equivalent is 0000 0100 0000 0010. This value indicates that bit B1 and bit B10 are
set.
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
** > > > > > > > > > > > > > > *
0 0 0 0 0 1 0 0 0 0 0 0 0 0 1 0
* Least significant bit
** Most significant bit
