Model 2651A High Power System SourceMeter® Instrument Reference Manual Appendix A: Maintenance
2651A-901-01 Rev. A / March 2011 A-5
5. Remove the USB flash drive from your PC and insert it into the USB port on the front panel of the
Model 2651A.
6. From the Model 2651A front panel, press the MENU key
7. Scroll to the UPGRADE menu item (by turning the navigation wheel
), and then press the
ENTER key.
8. Scroll to and select the file (located on the USB flash drive) that contains the appropriate version
of firmware.
9. Press the ENTER key to upgrade the firmware.
CAUTION
Do not turn the Model 2651A off while an upgrade is in progress.
Firmware upgrade using the instrument web interface
To upgrade the firmware from the web interface:
1. From the left navigation area, select Flash Upgrade.
2. Log in if necessary.
3. Click Upgrade Firmware.
4. A file selection dialog box is shown.
5. Select the file that contains the appropriate version of firmware.
6. Click Open. A progress dialog box is displayed. When the upgrade begins, the front panel display
will also display the progress.
7. After the instrument automatically restarts, it will be ready for use.
