Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-122 2651A-901-01 Rev. A / March 2011
lan.timedwait
This attribute contains the LAN timed-wait state interval.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes LAN restore defaults Nonvolatile memory 20
Usage
timeout = lan.timedwait
lan.timedwait = timeout
timeout
The LAN timed-wait state interval in seconds.
Details
This attribute controls the amount of time that resources are allocated to closed TCP connections. When a TCP
connection is closed, the connection is put in a timed-wait state and resources remain allocated for the
connection until the timed-wait state ends. During the timed-wait interval, the instrument processes delayed
packets that arrive after the connection is closed.
Use this attribute to tailor the timed-wait state interval for the instrument.
Also see
lan.restoredefaults() (on page 7-114)
lan.trigger[N].assert()
This function simulates the occurrence of the trigger and generates the corresponding event ID.
Type TSP-Link accessible
Affected by Where saved Default value
Function Yes
Usage
lan.trigger[N].assert()
N
The LAN event number (1 to 8)
Details
Generates and sends a LAN trigger packet for the LAN event number specified.
Sets the pseudostate to the appropriate state.
The following indexes provide the listed events:
• 1:LAN0
• 2:LAN1
• 3:LAN2
• …
• 8:LAN7
