Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-284 2651A-901-01 Rev. A / March 2011
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
For example, to set bit B10, set operationRegister to 1024.
Example
status.operation.instrument.trigger_blender.enable = 1024
Sets the TRGOVR bit of the
operation status trigger
blender summary enable
using a decimal value.
Also see
Operation Status Registers (on page E-20)
status.operation.instrument.trigger_blender.trigger_ov
errun.* (on page 7-284)
status.operation.instrument.trigger_blender.trigger_overrun.*
This attribute contains the operation status trigger blender overrun register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 30 (All bits set)
Usage
operationRegister =
status.operation.instrument.trigger_blender.trigger_overrun.condition
operationRegister =
status.operation.instrument.trigger_blender.trigger_overrun.enable
operationRegister =
status.operation.instrument.trigger_blender.trigger_overrun.event
operationRegister =
status.operation.instrument.trigger_blender.trigger_overrun.ntr
operationRegister =
status.operation.instrument.trigger_blender.trigger_overrun.ptr
status.operation.instrument.trigger_blender.trigger_overrun.enable =
operationRegister
status.operation.instrument.trigger_blender.trigger_overrun.ntr =
operationRegister
status.operation.instrument.trigger_blender.trigger_overrun.ptr =
operationRegister
operationRegister
The operation status trigger blender overrun register's status. A zero (0) indicates no
bits set (also send 0 to clear all bits); other values indicate various bit settings
