Keithley 2651A Reference Manual

Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 7: Command reference
2651A-901-01 Rev. A / March 2011 7-257
measurementRegister
The measurement event instrument summary register status. A zero (0)
indicates no bits set (also send 0 to clear all bits); other values indicate various
bit settings
Details
These attributes are used to read or write to the measurement event instrument summary registers. Reading a
status register returns a value. The binary equivalent of the returned value indicates which register bits are set.
The least significant bit of the binary number is Bit B0, and the most significant bit is Bit B15. For example,
assume the value 2 is returned for the enable register. The binary equivalent is 0000 0000 0000 0010. This value
indicates that bit B1 (SMUA) is set.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register sets
(on page E-
2) and Enable and transition registers
(on page E-18). The individual bits of this register have the following
meanings:
Bit Value Description
B0 Not used Not applicable.
B1
status.measurement.instrument.SMUA
Set bit indicates one or more enabled bits of the
measurement event SMU A summary register
is set.
Bit B1 decimal value: 2
Binary value: 0000 0010
B2-B15 Not used Not applicable.
As an example, to set bit B1 of the measurement event instrument summary enable register, set
status.measurement.instrument.enable = status.measurement.instrument.SMUA.
In addition to the above constant, measurementRegister can be set to the decimal equivalent of the bit to set.
Example
status.measurement.instrument.enable =
status.measurement.instrument.SMUA
Sets the SMU A bit of the
measurement event instrument
summary enable register using a
constant.
Also see
Measurement Event Registers (on page E-23)
status.measurement.instrument.smuX.*
This attribute contains the registers of the measurement event SMU X summary register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 387 (All bits set)
