Keithley 2651A Reference Manual

Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-290 2651A-901-01 Rev. A / March 2011
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register sets (on page E-
2) and Enable and transition registers
(on page E-18). The individual bits of this register have the following
meanings:
Bit Value Description
B0-B9 Not used Not applicable
B10
status.operation.instrument.tsplink.TRIGGER_OVERRUN
status.operation.instrument.tsplink.TRGOVR
Set bit indicates one or
more enabled bits for the
operation status TSP-
Link overrun register is
set.
Bit B10 decimal value:
1024
Binary value:
0100 0000 0000
B11-
B15
Not used Not applicable
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
For example, to set bit B10, set operationRegister to 1024.
Example
status.operation.instrument.tsplink.enable = 1024
Sets the trigger overrun bit of
the operation status TSP-Link
summary enable register
using a decimal value.
Also see
Operation Status Registers (on page E-20)
status.operation.instrument.tsplink.trigger_ov
errun.* (on page 7-290)
status.operation.instrument.tsplink.trigger_overrun.*
This attribute contains the operation status TSP-Link overrun register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 14 (All bits set)
