Keithley 2651A Reference Manual

Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-12 2651A-901-01 Rev. A / March 2011
Usage
result = bit.get(value, index)
result
Result of the bit manipulation
value
Specified number
index
One-based bit position within value to get (1 to 32)
Details
This function returns the value of the bit in value at index. This is the same as returning value with all other
bits set to zero (0).
The least significant bit of value is at index position 1; the most significant bit is at index position 32.
If the indexed bit for the number is set to zero (0), the result will be zero (0).
Example
testResult = bit.get(10, 4)
print(testResult)
The binary equivalent of decimal 10 is 1010. If you
get the bit at index position 4, the returned decimal
value is 8.
Output: 8.00000e+00
Also see
bit.clear() (on page 7-11)
bit.set() (on page 7-13)
bit.test()
(on page 7-15)
bit.toggle()
(on page 7-15)
Logical operators
(on page 6-22)
bit.getfield()
This function returns a field of bits from the value starting at the specified index position.
Type TSP-Link accessible
Affected by Where saved Default value
Function No
Usage
result = bit.getfield(value, index, width)
result
Result of the bit manipulation
value
Specified number
index
One-based bit position within value to get (1 to 32)
width
The number of bits to include in the field (1 to 32)
Details
A field of bits is a contiguous group of bits. This function retrieves a field of bits from value starting at index.
The index position is the least significant bit of the retrieved field. The number of bits to return is specified by
width.
The least significant bit of value is at index position 1; the most significant bit is at index position 32.
