Model 2651A High Power System SourceMeter® Instrument Reference Manual Section 3: Functions and features
2651A-901-01 Rev. A / March 2011 3-79
Bit B8 B7 B6 B5 B4 B3 B2 B1
Annunciator
SMPL STAR TRIG ARM AUTO 4W MATH FILT
Weighted value* 128 64 32 16 8 4 2 1
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
* The weighted values are for bits that are set to “1.” Bits set to “0” have no value.
Not all of the above indicators shown in above table may used by the Model 2651A.
Local lockout
The front-panel EXIT (LOCAL) key is used to cancel remote operation and return control to the front
panel. However, this key can be locked-out to prevent a test from being interrupted. When locked, this
key becomes a NO-OP (no operation). Configure the following attribute to lock or unlock the
EXIT (LOCAL) key:
display.locallockout = lockout
Where lockout is set to one of the following values:
0 or display.UNLOCK
1 or display.LOCK
Example:
The following programming example illustrates how to lock out the EXIT (LOCAL) key:
display.locallockout = display.LOCK
Load test menu
The LOAD TEST menu lists tests (USER, FACTORY, and SCRIPTS) that can be run from the front
panel. Factory tests are preloaded and saved in nonvolatile memory at the factory. They are available
in the FACTORY TESTS submenu. Named scripts that have been loaded into the run-time
environment can be selected from the SCRIPTS submenu. Refer to Manage scripts
(on page 6-3) for
additional information.
User tests
User tests can be added or deleted from the to the USER TESTS submenu.
