Keithley 2651A

Section 7
Command reference
In this section:
Command programming notes ................................................. 7-1
Using the command reference ................................................. 7-4
Commands ............................................................................... 7-8
Command programming notes
Placeholder text
This manual uses italicized text to represent the parts of remote commands that must be replaced by
user specified values. The following examples show typical uses of italicized text:
Example 1:
gpib.address = address
Where:
address is an integer (0 to 30) that you specify. For example, to set this attribute to 15 you would
send:
gpib.address = 15
Example 2:
digio.trigger[N].assert()
Where:
N is an integer (1 to 14) that you specify. For example, to assert trigger line 7 you would send:
digio.trigger[7].assert()
To assert trigger line with a variable as the integer, you would send:
triggerline = 7
digio.trigger[triggerline].assert()
