Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-300 2651A-901-01 Rev. A / March 2011
Example 2
-- 18432 = binary 0100 1000 0000 0000
operationRegister = 18432
status.operation.enable = operationRegister
Sets bits B11 and B14 of the operation
status user enable register using a
decimal value.
Also see
status.operation.* (on page 7-266)
Operation Status Register
(on page E-21)
status.questionable.*
These attributes manage the status model's questionable status register set.
Type TSP-Link accessible Affected by Where saved Default value
Attribute - - - - - - - -
.condition (R) Yes Not applicable Not saved Not applicable
.enable (RW) Yes Status reset Not saved 0
.event (R) Yes Status reset Not saved 0
.ntr (RW) Yes Status reset Not saved 0
.ptr (RW) Yes Status reset Not saved 13,056 (All bits set)
Usage
quesRegister = status.questionable.condition
quesRegister = status.questionable.enable
quesRegister = status.questionable.event
quesRegister = status.questionable.ntr
quesRegister = status.questionable.ptr
status.questionable.enable = quesRegister
status.questionable.ntr = quesRegister
status.questionable.ptr = quesRegister
quesRegister
The questionable status register's status. A zero (0) indicates no bits set (also send
0 to clear all bits); other values indicate various bit settings
Details
These attributes are used to read or write to the questionable status registers. Reading a status register returns a
value. In the binary equivalent, the least significant bit is bit B0, and the most significant bit is bit B15. For
example, if a value of 1.02400e+04 (which is 10,240) is read as the value of the condition register, the binary
equivalent is 0010 1000 0000 0000. This value indicates that bits B11 and B13 are set.
B15 B14 B13 B12 B11 B10 B9 B8 B7 B6 B5 B4 B3 B2 B1 B0
** > > > > > > > > > > > > > > *
0 0 1 0 1 0 0 0 0 0 0 0 0 0 0 0
* Least significant bit
** Most significant bit
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register sets (on page E-
2) and Enable and transition registers
(on page E-18). The individual bits of this register have the following
meanings:
