Keithley 2651A Reference Manual

Section 7: Command reference Model 2651A High Power System SourceMeter® Instrument Reference Manual
7-344 2651A-901-01 Rev. A / March 2011
Details
The trigger.timer[N].reset() function resets the following attributes to their factory defaults:
• trigger.timer[N].count
• trigger.timer[N].delay
• trigger.timer[N].delaylist
• trigger.timer[N].passthrough
• trigger.timer[N].stimulus
It also clears trigger.timer[N].overrun.
Also see
trigger.timer[N].count (on page 7-339)
trigger.timer[N].delay
(on page 7-340)
trigger.timer[N].delaylist (on page 7-341)
trigger.timer[N].overrun
(on page 7-342)
trigger.timer[N].passthrough
(on page 7-343)
trigger.timer[N].stimulus
(on page 7-344)
trigger.timer[N].stimulus
This attribute specifies which event starts the timer.
Type TSP-Link accessible Affected by Where saved Default value
Attribute (RW) Yes Instrument reset
Trigger timer N reset
Not saved 0
Usage
eventID = trigger.timer[N].stimulus
trigger.timer[N].stimulus = eventID
eventID
The event that triggers the timer delay
N
A number representing a trigger timer number (1 to 4)
Details
The eventID parameter may be one of the trigger event IDs shown in the following table.
Trigger event IDs*
Event ID Event description
smuX.trigger.SWEEPING_EVENT_ID
Occurs when the SMU transitions from the idle state
to the arm layer of the trigger model
smuX.trigger.ARMED_EVENT_ID
Occurs when the SMU moves from the arm layer to
the trigger layer of the trigger model
smuX.trigger.SOURCE_COMPLETE_EVENT_ID
Occurs when the SMU completes a source action
smuX.trigger.MEASURE_COMPLETE_EVENT_ID
Occurs when the SMU completes a measure action
